FT-Viggen

Name: FT-Viggen
SKU: FT001
Availability: InStock

The FT Viggen is a rule breaker. It’s a jet that can slow down to a crawl and not stall. Yet it can be fast and track like an arrow. It has a precise and locked in feel. These characteristics make the FT Viggen a great EDF trainer. The fact that you don’t have to fly fast all the time and be afraid of stalling makes the FT Viggen so enjoyable to fly. This plane will teach you about the nature and feel of an EDF power system in a safe and controlled manner. The FT Viggen can be flown on either an EDF or a propeller setup. All the way from a light 24 gram motor setup (440 grams flying weight), up to a 70mm EDF with a 4S 3000mAh (880 grams flying weight). The FT Viggen is the first Super Series speed build kit to be added to our store. The Super Series features intermediate build techniques and high performance flight characteristics.

Specifications:

Weight Without battery: 600gms
Wingspan: 25.5 inches (700mm)
CG Location: 5.25in/133mm from Leading edge of rudder
Control Throws: Elevons: 9⁰ – 12⁰ EXPO: 40⁰

Recommended Equipment:

EDF: 1000-1200 Watts.
Minimum thrust 1100gms.
ESC: 75-90Amps
Motor: 2300kv-2800kv Motor
ESC: 40-60 amps
Battery: 2200-3300 mAH 4s
Servos: (2) 9 gram servos
For Thrust Vectoring Use Metal gear servos.

Whats Included :

Fliteboard Pro (4 Nos)
Aeroply Parts
- Thrust Vectoring Mount
- FT-Elements Firewall
- Control Horns (2)
Pushrods (4pcs) 10cmx2, 40cmx2
Pushrod Connectors (2)
Velcro
Wire Set for Thrust Vectoring (3Pcs)
Pushrod Guide Tube (2)
Posterboard Exhaust Tube
Paper knife
Decals
Data Sheet

FT Viggen | Flite Test

FT Viggen – BUILD | Flite Test

Useful Links

Expert Advice

Keep the speed up when flying this airplane. Fly it low, fly it fast, buzz around and have some fun ! Fly around with friends or chase them around with a simple FPV setup. This plane is just too much fun !

This kit has been based on the Flite Test plans freely available. Several modifications have been made to the original plans to suit the materials available to get the best performance/balance. For more information please read up here :

Kit Includes:

The standard kit contains Laser Cut Sheets and hardware for assembling the airframe only. You will need the electronics pack + radio equipment + battery/charger to fly this airplane.

FliteBoard Pro Sheets:

FliteBoard Pro: Sheet A

FliteBoard Pro: Sheet B

FliteBoard Pro: Sheet C

FliteBoard Pro: Sheet D

Kit accessories:

Decals

Datasheet

Packaging details:

We want the kits to reach you in perfect condition. Laser cut Foamboard sheets are first shrink-wrapped together . Then the Sheet pack + accessories are sealed in a poly bag. Which is further bubble wrapped, which then is packed in a strong 5-ply corrugated box. Then the whole box is put into another 5 ply box to give it maximum safety.

Shrink Wrapped and sealed in plastic bag
